ISR 18V-30 PHX Industrial

ISR 18V-30 PHX Industrial

Consistent, reliable & affordable 18V smart solution made for industrial assembly lines  Extended lifetime for optimal operation without part failure, industrial grade clutch endurance & switch cycles boosting screw counts  Precision clutch with auto-shutoff, in combination with special engineered gearbox enabling 2X* higher speed output consistency and torque accuracy  Slim handle, light weight & short head length to minimize operation fatigue and maximize application flexibility

Functions & key features

Longer motor life - more runtime - more power thanks to brushless motor
Stops overriding if set torque level is reached, reduces wear and tear of clutch and resulting noise. Function can be switched off
Near-field communication enabling communication between tools & electronic devices. NFC offers simplified & affordable wireless connection solution for smart manufacturing
Long lifetime product design
Ergonomic handle with unique texturing designed for high-frequency application to reduce operation fatigue
Change variant
Check availability on location
Find a local dealer
ISR 18V-30 PHX Professional 0 601 9M7 100
Find a local dealer

Select a variant

Your Selection

ISR 18V-30 PHX

Order number: 0 601 9M7 100

Find a local dealer
Your selection

Your Selection

ISR 18V-30 PHX

Order number: 0 601 9M7 1F0

Find a local dealer
Select Variant

Technical data

Additional data

Torque (hard)
1.6 – 7.6 Nm
Speed
0 – 1,400 rpm
Auto Shutoff Torque
1.6 - 7.6 Nm
Bit holder
1/4'' Hex Uni
Direction of rotation
R/L
Weight
0.7 kg
Brushless motor
Connector type
Shut-off clutch
Description
When you’re fastening thousands of screws a day in an assembly line, you need a heavy-duty tool you can rely on to deliver long-term, accurate tightening and consistent performance. Our ISR 18V-30 PHX Industrial cordless drill driver offers up to twice the standard speed output consistency and torque accuracy thanks to its special engineering. Equipped with a precision clutch, this durable tool gives you significant performance outcome and extremely high production efficiency, especially in tightening applications for industrial assembly lines. The hex-head universal bit locker ensures a quick and dependable exchange of screw bits. What’s more, this smart drill driver makes keeping track of tools easy with its embedded NFC technology for inventory management and maintenance reminders. The ISR 18V-30 Industrial cordless drill driver made for machine screw tightening in industrial assembly lines.
Torque, from (hard)
9 Nm
Torque, to (hard)
30 Nm
Speed, from
0 rpm
Speed, up to
1,400 rpm
Auto Shutoff Torque, from
1.6 Nm
Auto Shutoff Torque, to
7.6 Nm
ISR 18V-30 PHX

* You can find more information about the deviations in the following link: Technical features of products

Need a spare part?

Here you will find the right spare parts for your professional Bosch tool quickly and easily.

Select a part

Order online

Pay

Receive your item

Find a spare part

Downloads

User Manual

User Manual | ISR 18V-30 PHX Instruction manual (PDF 3.0 MB) Instruction manual | GAL 18V-40 (PDF 2.2 MB)
Product data sheet Product data sheet | ISR 18V-30 PHX (PDF 1.5 MB)
